warning
Fire or projection hazard.
Keep away from heat, hot surfaces, sparks, open flames and other ignition sources. No smoking.
manufacturer
RWS GmbH / Kronacher Str. 63 / 90765 Fürth / www.rws-technology.com
Centrefire rifle cartridges
GECO PLUS
Hunting
GECO PLUS is synonymous with deep penetration and game preservation (even in the case of larger game).
Calibers:
6,5x55 SE
.270 Win.
7x64
7x65 R
7 mm Rem. Mag.
.308 Win.
.30-06 Spring.
.300 Win. Mag.
8x57 JS
8x57 JRS
9,3x62
9,3x74 R
- Penetrates deeply and preserves game (even in the case of larger game).
- Reliable effectiveness in heavy game and bone hits
- GECO BONDING provides high precision and deformation you can count on
- Control of the deformation through the visible predetermined breaking points in the jacket
GECO PLUS
All available calibers
Calibers:
- 6,5x55 SE
- .270 Win.
- 7x64
- 7x65 R
- 7 mm Rem. Mag.
- .308 Win.
- .30-06 Spring.
- .300 Win. Mag.
- 8x57 JS
- 8x57 JRS
- 9,3x62
- 9,3x74 R
GECO 8x57 JRS PLUS 12,7g
- Item no:
- 2317846
- Bullet type:
- Bonded
- Bullet Weight:
- 12.7 g / 196 gr
- Barrell Length:
- 600 mm / 23.62 in
- Ballistic Coefficient:
- 0.346
- Caliber:
- 8x57 JRS
- Unit size:
- 20
- Lead:
- Yes
- Recoil:
- Medium
- Usage for
- Light GameMedium GameHeavy Game
Ballistic Data
- metric
- imperial
Velocity
| V0 [m/s] | 710 |
|---|---|
| V50 [m/s] | 670 |
| V100 [m/s] | 632 |
| V150 [m/s] | 595 |
| V200 [m/s] | 560 |
| V250 [m/s] | 526 |
| V300 [m/s] | 493 |
Energy
| E0 [J] | 3201 |
|---|---|
| E50 [J] | 2851 |
| E100 [J] | 2536 |
| E150 [J] | 2248 |
| E200 [J] | 1991 |
| E250 [J] | 1757 |
| E300 [J] | 1543 |
Zero Range
| 100 m | MRD* 147 m | |
|---|---|---|
| 50m | 0.2 | 2.2 |
| 100m | 4 | |
| 150m | -6.4 | -0.4 |
| 200m | -19.7 | -11.8 |
| 250m | -40.9 | -30.9 |
| 300m | -70.9 | -59 |
*Most Recommended Distance
Velocity
| V0 [ft/s] | 2329 |
|---|---|
| V50 [ft/s] | 2210 |
| V100 [ft/s] | 2095 |
| V150 [ft/s] | 1984 |
| V200 [ft/s] | 1876 |
| V250 [ft/s] | 1772 |
| V300 [ft/s] | 1672 |
Energy
| E0 [ft/lbs] | 2361 |
|---|---|
| E50 [ft/lbs] | 2125 |
| E100 [ft/lbs] | 1910 |
| E150 [ft/lbs] | 1713 |
| E200 [ft/lbs] | 1532 |
| E250 [ft/lbs] | 1366 |
| E300 [ft/lbs] | 1217 |
Zero Range
| 100 yds | MRD* 159 yds | |
|---|---|---|
| 50yds | -0.1 | 0.7 |
| 100yds | 1.5 | |
| 150yds | -1.9 | 0.4 |
| 200yds | -6 | -2.9 |
| 250yds | -12.5 | -8.7 |
| 300yds | -21.9 | -17.2 |
*Most Recommended Distance
